OG MINI

Mini Size of Oxygen Generator for Laboratory

OG MINI is a range of compact, silent and efficient high purity Nitrogen generators for laboratory analytical instruments & devices. Each generator is endowed with 4.5" touch screen HMI with integrated PLC to obtain a total control of the process and of the its functionalities, managing in supplying Oxygen at the exact purity, pressure and small flow. In additional, plug & play solutions with built-in oil-free and tank are available on request.

The technology that OG MINI utilizes is the PSA process (Pressure Swing Adsorption). It is the engine that drives the separation of oxygen from air, with a degree of purity over 93%. It is a purely physical process denominated adsorption. During the adsorption step, nitrogen is adsorbed at elevated pressure and oxygen is produced. During the regeneration step, nitrogen is desorbed via depressurization and the adsorbents are regenerated. In order to convert this batch process into a continuous process, OG MINI uses two adsorbent vessels. As one is adsorbing, the other is regenerating and vice versa.

Key Features

  • Integrated with PLC + 4.5” HMI touch screen
  • Display of real time operation status, parameters trend graph and history data
  • Energy efficient control - automatic turn down to STANDBY when no consumption
  • Data logger
  • Ethernet interface
  • Internal piping & fittings in stainless steel
  • Equipped with air inlet filters

Option

  • Integrated with build-in oil-free air compressor
  • Integrated with adsorption dryer
  • Integrated with oxygen sensor and
  • Integrated with oxygen flow meter
  • Piping distribution from generator outlet to point of use

Typical Application

  • Laboratories analysis
  • Any other application requiring small flow rates of oxygen

Product Information

Technology EmployPressure Swing Adsorption
Controlled systemPLC + 4.5” colour touch screen
Product Purity93% (+/- 3%)
Capacity2.2 – 6 NL/min
Inlet Air PressureMin. 6 – max. 10 bar
Outlet PressureInlet pressure minus 1 bar (+/- 0.5)
Product Dew Point-35°C PDP (+/- 5)
Operating Temperature5 – 45 oC
Electrical Supply230V / 50Hz / 1Ph
Noise Level<75 dB

Performance Data

Model

Inlet  Pressure

Flow Rate vs Purity

Connection

Power Supply

Dimension

Weight

Bar(g)

NL/min @ 93%

Inlet

Outlet

mm

kg

MINI-1

7

2.2

1/2"

1/2"

230V 50-60Hz 0.5kW

500x500x760

80

MINI-2

7

6.0

1/2"

1/2"

230V 50-60Hz 0.5kW

500x700x960

128

Indicated Nitrogen flow rates (±5% tolerance) are in NL/min and they are valid for generators operating at atmospheric conditions +20°C, 1013 mbar and 60% RH, 8 bar(g) inlet feed air pressure. Definition of Nm3 based on reference conditions 0°C, 101.325 Pa(a) and dry basis. For performances in other conditions please contact directly the manufacturer. The manufacturer reserves the right of modifying present data without any prior advice. Please always report to his indications.
